HEM
Steel grade: S235; S355
Length: L-6m.; L-12m.
HEM metal beams are employed to increase stability and durability of steel constructions. Black steel beams HEM can withstand heavy loads and are widely used in steel constructions of commercial and warehousing facilities, as well as in building skyscrapers, sports stadiums and large warehouses. Metal HEM beams are suitable for any metal construction project and for any circumstances.
The structural strength of HEM steel beams depends on cross-sectional dimensions and shape, size and length, steel of grade S235 or S275 or S355. HEM steel beams are the largest beams. HEM beams are widely used in the biggest black metal structures where it is necessary to withstand heavy loads. Our company offers HEM metal beams sizes L-12000mm; L-12100mm.
HEM beams | Height h | Width b | Thickness w | Thickness t | Radius r | Height h1 | Height d | Weight kg/m | m2/m |
|---|---|---|---|---|---|---|---|---|---|
HEM 100 | 120 | 106 | 12 | 20 | 12 | 80 | 56 | 41.8 | 0,619 |
HEM 120 | 140 | 126 | 12.5 | 21 | 12 | 98 | 74 | 52.1 | 0,738 |
HEM 140 | 160 | 146 | 13 | 22 | 12 | 116 | 92 | 63.2 | 0,857 |
HEM 160 | 180 | 166 | 14 | 23 | 15 | 134 | 104 | 76.2 | 0,970 |
HEM 180 | 200 | 186 | 14.5 | 24 | 15 | 152 | 122 | 88.9 | 1,089 |
HEM 200 | 220 | 206 | 15 | 25 | 18 | 170 | 134 | 103 | 1,203 |
HEM 220 | 240 | 226 | 15.5 | 26 | 18 | 188 | 152 | 117 | 1,322 |
HEM 240 | 270 | 248 | 18 | 32 | 21 | 206 | 164 | 157 | 1,460 |
HEM 260 | 290 | 268 | 18 | 32.5 | 24 | 225 | 177 | 172 | 1,575 |
HEM 280 | 310 | 288 | 18.5 | 33 | 24 | 244 | 196 | 189 | 1,694 |
HEM 300 | 340 | 310 | 21 | 39 | 27 | 262 | 208 | 238 | 1,832 |
HEM 320 | 359 | 309 | 21 | 40 | 27 | 279 | 225 | 246 | 1,866 |
HEM 340 | 377 | 309 | 21 | 40 | 27 | 297 | 243 | 248 | 1,902 |
HEM 360 | 395 | 308 | 21 | 40 | 27 | 315 | 261 | 250 | 1,934 |
HEM 400 | 432 | 307 | 21 | 40 | 27 | 352 | 298 | 256 | 2,004 |
HEM 450 | 478 | 307 | 21 | 40 | 27 | 398 | 344 | 263 | 2,096 |
HEM 500 | 524 | 306 | 21 | 40 | 27 | 444 | 390 | 270 | 2,184 |
HEM 550 | 572 | 306 | 21 | 40 | 27 | 492 | 438 | 278 | 2,280 |
HEM 600 | 620 | 305 | 21 | 40 | 27 | 540 | 486 | 285 | 2,372 |
HEM 650 | 668 | 305 | 21 | 40 | 27 | 588 | 534 | 293 | 2,468 |
HEM 700 | 716 | 304 | 21 | 40 | 27 | 636 | 582 | 301 | 2,560 |
HEM 800 | 814 | 303 | 21 | 40 | 30 | 734 | 674 | 317 | 2,746 |
HEM 900 | 910 | 302 | 21 | 40 | 30 | 830 | 770 | 333 | 2,934 |
HEM 1000 | 1008 | 302 | 21 | 40 | 30 | 928 | 868 | 349 | 3,130 |
